Product Description
A 3.0" Clear View II Vari-angle Touchscreen LCD with 1,040k-dot resolution provides composition and playback viewing. Its tilt and swivel capability makes it easy to compose your shots at odd angles and a smudge-resistant coating keeps the monitor clear. Intuitive touchscreen operation includes Touch Autofocus.
Full HD 1080p at 30 fps and 24 fps is supported with Movie Servo for continuous autofocus during shooting. Manual exposure is provided in video mode and 60 fps is possible when shooting at 720p HD. A built-in stereo microphone with manual audio level adjustment is provided for quality audio recording with your videos.
Scene Intelligent Auto Mode automatically makes the optimal camera adjustments based on scene recognition, and improved scene detection is particularly helpful when shooting night scenes. Advanced imaging features such as Handheld Night Scene and HDR Backlight Control make capturing difficult shots easy, and seven Creative Filters add expressive touches to your images and can even be viewed in real time during Live View shooting.
The EOS Rebel T5i utilizes SD/SDHC/SDXC memory cards and is compatible with the full line of Canon EF and EF-S lenses.
Imaging | |
Lens Mount | Canon EF Canon EF-S |
Camera Format | Canon APS-C (1.6x Crop Factor) |
Pixels | Actual: 18.5 Megapixel Effective: 18 Megapixel |
Max Resolution | 17.9 MP: 5184 x 3456 |
Aspect Ratio | 3:2 |
Sensor Type / Size | CMOS, 22.3 x 14.9 mm |
File Formats | Still Images: JPEG, RAW Movies: MOV, MPEG-4 AVC/H.264 Audio: Linear PCM |
Bit Depth | 14-Bit |
Dust Reduction System | Yes |
Memory Card Type | SD SDHC SDXC |
Focus Control | |
Focus Type | Autofocus |
Focus Mode | Continuous-Servo AF (C), Manual Focus (M), Single-servo AF (S) |
Autofocus Points | 9 |
Viewfinder/Display | |
Viewfinder Type | Pentamirror, Optical |
Viewfinder Coverage | 95% |
Viewfinder Magnification | Approx. 0.87x |
Diopter Adjustment | -3 to +1 m |
Display Screen | 3" Rear Touchscreen Tilting Live Preview LCD (1,040,000) |
Screen Coverage | 100% |
Exposure Control | |
ISO Sensitivity | Auto, 100-12800 (Extended Mode: 100-25600) |
Shutter | Type: Electronic & Mechanical Speed: 30 - 1/4000 Seconds |
Metering Method | Average Metering, Center-Weighted Average Metering, Multi-Zone Metering, Partial Metering, Spot Metering |
Exposure Modes | Modes: Aperture Priority, Auto, Flash Off, Manual, Programmed Auto, Shutter Priority Metering Range: EV 1.0 - EV 20.0 Compensation: -5 EV to +5 EV (in 1/3 or 1/2 EV Steps) |
White Balance Modes | Auto, Cloudy, Custom, Daylight, Flash, Fluorescent (White), Shade, Sunset, Tungsten, Twilight |
Flash | |
Built-in Flash | Yes |
Flash Compensation | -2 EV to +2 EV (in 1/3 or 1/2 EV steps) |
Dedicated Flash System | eTTL Remote Firing |
External Flash Connection | Hot Shoe |
AV Recording | |
Video Recording | Yes, NTSC/PAL |
File Size | 1920 x 1080p (Full HD) 1280 x 720p (HD) 640 x 480p (SD) |
Frame Rate | @ 1920 x 1080: 30 fps, 25 fps, 24 fps @ 1280 x 720: 60 fps, 50 fps @ 640 x 480: 30 fps, 25 fps |
Exposure Control | Auto: Shutter Speed, Aperture, ISO Manual: Shutter Speed, Aperture, ISO |
ISO Sensitivity | Auto, 100 - 6400, Expandable to 12800 |
Exposure Compensation | -3 EV to +3 EV (in 1/3 EV steps) |
Focus | Auto Manual Continuous Auto |
Max Video Clip Length | 1920 x 1080: 29 Minutes, 59 Seconds 1280 x 720: 29 Minutes, 59 Seconds 640 x 480: 29 Minutes, 59 Seconds |
Audio Recording | Optional External Mic: With Video (Stereo) |
Performance | |
Shutter Lag | 0.075 seconds |
Self Timer | 2 Seconds, 10 Seconds |
Connectivity | AV Output HDMI C (Mini) USB 2.0 |
Power | |
Battery | 1 x LP-E8 Rechargeable Lithium-Ion Battery Pack |
AC Power Adapter | ACK-E8 (Optional) |
Operating/Storage Temperature | Operating 32 to 104°F (0 to 40°C) Humidity: 0 - 85% |
Physical | |
Dimensions (W x H x D) | 5.2 x 3.9 x 3.1" / 13.2 x 9.9 x 7.9 cm |
Weight | 18.52 oz / 525.04 g Body Only without battery and card |
