Product Description
Moreover, this dynamic subwoofer will take your audio listening experience to a whole new level. The Optimum-12 offers an adjustable low-pass crossover, high-pass crossover, 13 - 240Hz frequency response, RCA line-level input/output, LFE input, and speaker-level inputs with 5-way binding posts. Enjoy the convenience of (4) customized listening modes, one-button 7-Band EQ room correction system, intuitive front-panel LCD display, Auto Turn On function, IR remote compatibility, and Night Mode function for conscience minded night time listeners.
With its hand-rubbed black gloss lacquer finish and cube-style design, magnetic video shielding, the Velodyne Optimum-12 is an ideal solution for home theater, whole house audio systems, and anywhere high quality, powerful bass projection is required.
Sub-Woofer | |
Type | Active |
Power Rating | 1200W RMS/2400W Peak |
Frequency Response | 13 - 240Hz (Overall), 21 - 120Hz (±3dB) |
Crossover Frequency | Low-Pass 40 - 120Hz (12dB octave, 24dB Ultimate) Adjustable |
Phase | 0°, 90°, 180°, 270° (Adjustable) |
Total Harmonic Distortion (THD) | <5% (typical) |
Magnetic Characteristics | 346 oz (21.6 lbs) |
Impedance | N/A |
Drivers | 12" (304.8mm) Resin Cone 9.7" (246.3mm) Piston |
Voice Coil | Dual Layer 3" (76.2mm) |
Enclosure | Sealed |
Inputs | Speaker Level, Line Level (RCA), LFE, Mic (for room calibration) |
Outputs | Speaker Level (80Hz High-Pass Crossover) |
Other | IR Input, 12V Trigger Input |
Shielded | Yes, Magnetic |
Construction | Not Specified By Manufacturer |
General | |
Dimensions (HxWxD) | 15.2 x 14.8 x 18.5" (386 x 375.9 x 469.9mm) |
Shipping Weight | 49 lbs (22.2kg) |
Power Requirements | 120VAC, 60Hz |
Color | Gloss Black |
